Model name: RUBY-E
Vehicle : Barrier-free city bus-City bus
Model number: BAA12EA-1
Chassis brand / model : IJI / D6123S05

Body size
Total length: 11,920 mm
Overall width: 2,495 mm
Overall height: 2,983 mm
Wheelbase: 5,950 mm
Front suspension length: 2,746 mm
Rear suspension length: 3,220 mm
Axle track: (front / rear) 2,096 / 1,836
Approach / departure angle: 6 ° / 7 °
A stepping ground: front door ? 350 mm, rear door ? 350 mm

Weight data
Maximum gross vehicle weight: 17,000 kg
Chassis weight: 5,010 kg

Main body configuration
Number of seats: 22
Standing number: 55
Door: a pair of bi-fold doors at front and rear
Windshield :,  laminated safety glass bonded in to the window frame.
Side windows:toughened glass and  laminated safety glass bonded in to the window frame.
Rear window:  laminated safety glass.
Mirrors: Manual adjustable
Air-conditioning system: SPAC_AC355 ceiling-mounted (Brand: sin shu che)

Chassis basic parameters
Frame: three-stage design, one step entrance
Maximum power: 194 kW (260 BHP) @ 2,000 RPM
Maximum speed: 80km / h
Maximum climbing capacity: 20
Minimum turning radius: 12m
Maximum braking distance: 10m
Automatic transmission: the ZF Ecomat 2_plus, 6HP502C
six-speed+reverse gearbox, integrated electronic control hydraulic retarder
Reduction ratio: 6.2
Suspension system: Wabco
electronically controlled pneumatic suspension control system
Tires and rims: 275/70 R22.5 "and 22.5" x 8.25 "(standard)
Braking System: Wabco pneumatic braking system

Electrical system
Fuel tank capacity: 185L
Voltage: 24 V
Battery: 2 x 12V/190 Ah
Generator: Prestolite AC172RA, 140 A/24 V

Subordinate equipment:
LED route indicator
GPS LED display
On and off ticket Lightbox
Pole / crossbar / pull ring
Armrest
Fence
Get off the bell
Seat
Fire extinguisher
Emergency hammer
Failure marked plate
Driving sunshade
Reversing radar
Turning and reversing buzzer
CITY BUS standard-a broadcast system
The exclusive accessibility District facilities
The slopes board (Ramp, Electric)

Optional device:
Reversing Monitor
The side of the car monitor
Rear route LED indicator
The slopes board (Ramp, electric)

Model name: RENEE-i
Vehicle type: short-distance intercity bus-Intercity
Model number: IHN12TB-1
Chassis brand / model: HINO / RK8JRSA

Body size
Total length: 11,653 mm
Overall width: 2,495 mm
Overall height: 3,250 mm
Wheelbase: 5,800 mm
Front suspension length: 2,452 mm
Rear suspension length: 3,401 mm
Axle track: (front / rear) 2,040 / 1,840
Approach / departure angle: 7 ° / 7 °

Weight data
Total weight: 14,500 kg
Chassis weight: 4,860 kg

Main body configuration
Number of seats: 37
Door: sliding door at front
Windshield :,  laminated safety glass bonded in to the window frame.
Side windows:toughened glass and  laminated safety glass bonded in to the window frame.
Rear window:  laminated safety glass.
Mirrors: Manual adjustable
Air-conditioning system: SPAC_AC262 Split
 (Brand: sin shu che)

Chassis basic parameters
Maximum power: 171.5kw (the 233PS) @ 2500RPM
Maximum speed: 95km / h
Maximum climbing capacity : 37.5
Minimum turning radius: 8,900 mm
Maximum braking distance: X
Transmission: manual, five-speed+reverse gearbox r
Reduction ratio: 5.125
Suspension system: Equal length of steel spring, attached double acting shock absorbers and stabilizer bar
Tires and rims :10.00-20-14PR / 20x7.00T-offset 162 mm
Brake system : double-loop, full pneumatic braking with brake automatic adjuster

Electrical system
Fuel tank capacity: 250L
Voltage: 24 V
Battery: 12V-540kC (150A. H) x 2 pics
Generator: 24V-90A

Subordinate equipment:
LED route indicator
GPS LED display
Luggage rack
Luggage compartment
Cup holder
Wind outlet and passenger reading lights combination
Front door armrests
Get off bell
Seat
Fire extinguisher
Emergency hammer
Failure marked plate
Driving sunshade
Parking sensor
Turning and reversing buzzer
The INTERCITY Standard AV system device

Optional device:
The side of the car monitor
Rear route LED indicator
GPRS System

Name of model: KESAVAN
Vehicle type : long-distance intercity bus-Intercity
Model number: IHN12FA-1
Chassis brand / model: HINO / RN8JSSA

Body size
Total length: 11,880 mm
Overall width: 2,495 mm
Overall height: 3,250 mm
Wheelbase: 6,000 mm
Front suspension length: 2,495 mm
Rear suspension length: 3,480 mm
Axle track: (front / rear) 2,040 / 1,820
Approach / departure angle: 7 ° / 7 °

Weight data
Maximum gross vehicle weight: 16,000 kg
Chassis weight: 5,190 kg

Main body configuration
Number of seats: 37

Door: sliding door at front and rear.
Windshield :,  laminated safety glass bonded in to the window frame.
Side windows:toughened glass and  laminated safety glass bonded in to the window frame.
Rear window:  laminated safety glass.
Mirrors: Manual adjustable
Air-conditioning system: SPAC_AC355 ceiling-mounted (Brand: sin shu che)

Chassis basic parameters
Frame: Step entrance type
Maximum power: 193 kW (263 PS) @ 2,500 RPM
Maximum speed: 113 km / h
Maximum climbing capacity: 31.9
Minimum turning radius: 9,100 mm
Maximum braking distance: x
Automatic transmission: : manual, five-speed+reverse gearbox
Reduction ratio: 4.3
Suspension system: air suspension, with a double-acting shock absorbers and levelling bar
Tires and Rims: 295/80R22.5 and 22.5x8.25-offset 165 mm
Brakes: Dual circuit, fully pneumatic brakes with brake automatic adjuster auxiliary brake, hydraulic retarder

Electrical system
Fuel tank capacity: 250L
Voltage: 24 V
Battery: 12V?540kC?150A∙h?x 2 pics
Generator: 24V?90A

Subordinate equipment:
GPS & GPRS system
Luggage rack
Luggage compartment
Cup holder
Wind outlet and passenger reading lights combination
Toilet
Front & the back door armrests
Fence
Seat
Fire extinguisher
Emergency hammer
Failure marked plate
Driving sunshade
Curtain
Reversing monitor
Turning and reversing buzzer
The INTERCITY Standard AV system device

Optional device:
The side of the car monitor
Rear route LED indicator

Model name: RENEE-i
Vehicle type: short-distance intercity bus-Intercity
Model number: IHN12TB-1
Chassis brand / model: HINO / RK8JRSA

Body size
Total length: 11,653 mm
Overall width: 2,495 mm
Overall height: 3,250 mm
Wheelbase: 5,800 mm
Front suspension length: 2,452 mm
Rear suspension length: 3,401 mm
Axle track: (front / rear) 2,040 / 1,840
Approach / departure angle: 7 ° / 7 °

Weight data
Total weight: 14,500 kg
Chassis weight: 4,860 kg

Main body configuration
Number of seats: 37
Door: sliding door at front
Windshield :,  laminated safety glass bonded in to the window frame.
Side windows:toughened glass and  laminated safety glass bonded in to the window frame.
Rear window:  laminated safety glass.
Mirrors: Manual adjustable
Air-conditioning system: SPAC_AC262 Split
 (Brand: sin shu che)

Chassis basic parameters
Frame: ?????
Maximum power: 171.5kw (the 233PS) @ 2500RPM
Maximum speed: 95km / h
Maximum climbing capacity : 37.5
Minimum turning radius: 8,900 mm
Maximum braking distance: X
Transmission: manual, five-speed+reverse gearbox r
Reduction ratio: 5.125
Suspension system: Equal length of steel spring, attached double acting shock absorbers and stabilizer bar
Tires and rims :10.00-20-14PR / 20x7.00T-offset 162 mm
Brake system : double-loop, full pneumatic braking with brake automatic adjuster

Electrical system
Fuel tank capacity: 250L
Voltage: 24 V
Battery: 12V-540kC (150A. H) x 2 pics
Generator: 24V-90A

Subordinate equipment:
LED route indicator
GPS LED display
Luggage rack
Luggage compartment
Cup holder
Wind outlet and passenger reading lights combination
Front door armrests
Get off bell
Seat
Fire extinguisher
Emergency hammer
Failure marked plate
Driving sunshade
Parking sensor
Turning and reversing buzzer
The INTERCITY Standard AV system device

Optional device:
The side of the car monitor
Rear route LED indicator
GPRS System
